Universal Compatibility Works with Thunderbolt 3, Thunderbolt 4, and USB-C laptops running Windows or macOS. Perfect for hot-desking, mixed deployment environments, and home office use. Thunderbolt Technology Allows users to transfer up to 40Gbps of data, video, and audio (10Gbps for USB-C 3.2 Gen2 laptops and 5Gbps for USB-C 3.2 Gen1 laptops) using the included 0.8m (2.6 ft.) Thunderbolt 3 cable, for a quick and powerful plug-and-play experience. Single or Dual 4K Video Output for Thunderbolt-Enabled Devices Extend visual productivity with the crisp resolution, contrast, and color depth of Ultra HD (Single or Dual 4K @ 60Hz) via the one HDMI 2.0 port and one additional Thunderbolt 3 port. USB-C Alt Mode devices support a single monitor via the HDMI port (DP1.2 at 4K/30Hz and DP1.4 at 4K/60Hz). 96W Power Delivery Charge any Thunderbolt 3, Thunderbolt 4 or USB-C-enabled laptop quickly and easily (USB-C laptops must support Power Delivery). Productive Desktop Setup This 10-port universal docking features multiple ports for connecting peripherals and accessories: two front USB-C 3.2 Gen2 ports (one 5V/1.5A/10Gbps and one 9V/2.22A/10Gbps), four USB-A ports (one front 3.2 Gen2 5V/0.9A/10Gbps, three rear with two supporting 3.2 Gen1 5V/0.9A/5Gbps and one 3.2 Gen2 5V/0.9A/10Gbps), one Gigabit Ethernet port, one audio combo jack, an HDMI 2.0 port, and a Thunderbolt 3 port (when used with USB-C Alt Mode laptops, this Thunderbolt 3 port is downgraded to USB 2.0 and does not support video or daisy chaining features). Horizontal and Vertical Placement Options Designed to support horizontal and vertical placement on the desktop. Free Kensington DockWorks Software For the best connection, performance, and security from your Kensington dock. Three-Year Warranty Rest assured knowing you’re covered by Kensington. If you’re looking for a universally compatible dock, with support for HDMI- and USB-C-based video, 96W Power Delivery, quick and efficient data transfer speeds, and horizontal and vertical placement options, the SD5560T Thunderbolt 3 and USB-C Dual 4K Hybrid Docking Station – 96W PD – Win/Mac has you covered. It’s a truly hybrid docking solution that requires no drivers or downloads, and works across operating systems (Windows and macOS), as well as device types (Thunderbolt 3, Thunderbolt 4, or USB-C). This dock supports up to two external displays (HDMI- and USB-C-based video) for Thunderbolt-based devices; quick and efficient data transfer speeds (40Gbps); and offers multiple ports for connecting peripherals and accessories, including two USB-C ports, four USB-A ports, one Gigabit Ethernet port, one audio combo jack, an HDMI 2.0 port, and an extra Thunderbolt 3 port (when used with USB-C Alt Mode laptops, this Thunderbolt 3 port is downgraded to USB 2.0 and does not support video or daisy chaining features). Three-year warranty.

Ports & interfaces
Connectivity technology	Docking
Host interface	Thunderbolt 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.0
DisplayPorts quantity	1
DC-in jack	Yes
USB Power Delivery	Yes
USB Power Delivery up to	96 W
DisplayPort version	1.2
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Product colour	Gray, Light Blue
Country of origin	China
Plug and Play	Yes
LED indicators	Power
Certification	FCC, IC, CE, UKCA, RCM, VCCI, CB, RoHS, ACCO RSL
Colour name	Pantone Cool Gray
Maximum refresh rate	60 Hz
Hub interfaces	Thunderbolt 3
Power
Power source type	DC
AC input voltage	100 - 240 V
Input current	3.5 A
Output voltage	21 V
Output current	8.57 A
Power connector	USB Type-C
Power supply	180 W
Software
Windows operating systems supported	Windows 10
Mac operating systems supported	MacOS
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	0 - 55%
Weight & dimensions
Width	5.71" (145 mm)
Depth	3.94" (100 mm)
Height	1.97" (50 mm)
Package width	8.27" (210 mm)
Package depth	5.31" (135 mm)
Package height	4.72" (120 mm)
Package weight	4.41 lbs (2 kg)
Design
Product colour	Gray, Light Blue
Country of origin	China
Windows operating systems supported	Windows 10
Mac operating systems supported	MacOS
LED indicators	Power
Certification	FCC, IC, CE, UKCA, RCM, VCCI, CB, RoHS, ACCO RSL
Packaging data
Package width	8.27" (210 mm)
Package depth	5.31" (135 mm)
Package height	4.72" (120 mm)
Package weight	4.41 lbs (2 kg)
Packaging content
User guide	Yes
Cables included	Thunderbolt
Warranty card	Yes
Technical details
User guide	Yes
