CyberPower PDU24005 provides output from a UPS unit, generator, or utility power to multiple connected devices in IT environments. Dual power cords can be plugged into separate power sources to provide redundancy to single-corded connected equipment. If the selected power source exceeds the desired thresholds or fails, the ATS PDU will automatically switch to the other power source to ensure continuous operation.

The unit comes with a hot-swappable multifunction readout that displays real-time vitals including current, input voltage, power consumption levels in amps and watts. The digital LCD display is also color configurable, allowing easy maintenance and monitoring of the ATS PDU. Users can change LCD’s colors to easily categorize devices between multiple machines in server room and IT environments. The firmware can also be conveniently upgraded via the USB port, ensuring the latest features and updates are available for users.

The product can be connected to a PC through the serial port to perform local control of the ATS PDU.

Design
PDU types	Metered
Mounting	Horizontal
Type	Single-phase
Display	LCD
Product colour	Black
Certification	FCC Class A, UL62368, EN 55032 Class A, IEC 62368
Rack capacity	1U
Housing material	Steel
Ports & interfaces
Power plug	C20 coupler
AC outlets quantity	10 AC outlet(s)
AC outlet types	C13 coupler, C19 coupler
USB ports quantity	1
Serial ports quantity	1
Ethernet LAN (RJ-45) ports	1
Features
LED indicators	Link, Status
Cable length	120.1" (3.05 m)
Certification	FCC Class A, UL62368, EN 55032 Class A, IEC 62368
Management features
Firmware upgradeable	Yes
Ergonomics
Display	LCD
LED indicators	Link, Status
Cable length	120.1" (3.05 m)
Power
Nominal input voltage	200 - 240 V
Maximum current	12 A
Nominal output voltage	200 - 240 V
Power protection features	Overload
AC input frequency	50 / 60 Hz
Circuit breaker	Yes
Certificates
Certification	FCC Class A, UL62368, EN 55032 Class A, IEC 62368
Compliance certificates	CB, CE, Federal Communications Commission (FCC), RoHS, UL
Sustainability
Sustainability compliance	Yes
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-15 - 95 °C
Storage relative humidity (H-H)	0 - 95%
Operating relative humidity (H-H)	0 - 95%
Operating altitude	0 - 157480.3" (0 - 4000 m)
Non-operating altitude	0 - 590551.2" (0 - 15000 m)
Operating temperature (T-T)	32 - 113 °F
Weight & dimensions
Weight	7.05 lbs (3.2 kg)
Width	17" (433 mm)
Depth	8.46" (215 mm)
Height	1.73" (44 mm)
Package width	21.7" (550 mm)
Package depth	15.7" (398 mm)
Package height	4.92" (125 mm)
Package weight	13.2 lbs (6 kg)
Packaging data
Package width	21.7" (550 mm)
Package depth	15.7" (398 mm)
Package height	4.92" (125 mm)
Package weight	13.2 lbs (6 kg)
Technical details
Sustainability compliance	Yes
Warranty period	2 year(s)
Compliance certificates	CB, CE, Federal Communications Commission (FCC), RoHS, UL
Logistics data
Warranty period	2 year(s)
