Various Sensor Connection
LG webOS smart signage platform helps to easily provide additional solutions by supporting simple connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.

Mobile & Web Monitoring
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of the SM5J series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations.

Compatible with AV Control System
The SM5J series supports Crestron Connected for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.

Real-Time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.

LG's Simple Advertisement Helper, Promota
Using LG's Promota application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more while recommending easy-to-use templates relevant to your industry.

Real-Time Promotion
With Beacon and Bluetooth Low Energy (BLE), shop managers can provide coupons and information in real-time.

Content Sharing
Content Mirroring among devices is available on a Wi-Fi network.

Wireless Access Point
The SM5J series operates as a virtual router which can be an wireless access point for mobile devices.

Display
Display diagonal	32"
Display resolution	1920 x 1080 pixels
Display brightness	400 cd/m²
HD type	Full HD
Response time	10 ms
Contrast ratio (typical)	1100:1
Contrast ratio (dynamic)	1000000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colors
Display technology	IPS
Haze rate	1%
Ports & interfaces
Ethernet LAN	Yes
HDMI ports quantity	3
Remote (IR) input	1
USB port	Yes
Ethernet LAN (RJ-45) ports	1
Wi-Fi	Yes
USB version	2.0
RS-232C	Yes
Audio
Number of built-in speakers	2
RMS rated power	20 W
Built-in speaker(s)	Yes
Design
Product design	Digital signage flat panel
Product colour	Black
VESA mounting	Yes
Panel mounting interface	200 x 200 mm
Orientation	Horizontal/Vertical
Bezel width (top)	0.512" (1.3 cm)
Bezel width (side)	0.512" (1.3 cm)
Bezel width (bottom)	0.709" (1.8 cm)
Performance
Purpose	Universal
Operating hours (hours/days)	24/7
HDCP	Yes
Ambient light sensor	Yes
HDCP version	2.2
Wi-Fi	Yes
Power
Power consumption (typical)	55 W
Heat dissipation	187.67 BTU/h
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Weight & dimensions
Width (with stand)	28.7" (729.4 mm)
Height (with stand)	18.9" (481 mm)
Depth (with stand)	6.07" (154.2 mm)
Weight (with stand)	14.3 lbs (6.5 kg)
Display width	28.7" (729.4 mm)
Display depth	2.19" (55.5 mm)
Display height	16.9" (428.9 mm)
Display weight	12.6 lbs (5.7 kg)
Packaging content
Remote control included	Yes
Cables included	AC, HDMI
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Logistics data
Harmonized System (HS) code	85285210
Packaging data
Remote control included	Yes
Cables included	AC, HDMI
Features
Harmonized System (HS) code	85285210
Technical details
Ambient light sensor	Yes
Weight (with stand)	14.3 lbs (6.5 kg)
Other features
Wi-Fi	Yes
Width (with stand)	28.7" (729.4 mm)
Height (with stand)	18.9" (481 mm)
Display technology	IPS
Depth (with stand)	6.07" (154.2 mm)
Bezel width (top)	0.512" (1.3 cm)
Bezel width (side)	0.512" (1.3 cm)
Bezel width (bottom)	0.709" (1.8 cm)
Weight (with stand)	14.3 lbs (6.5 kg)
