Enhance High-End Multi-Monitor Workstation
Maximize your high-end dual HD workstations by connecting them to the IOGEAR 4-Port 4K Dual View KVMP with HDMI(R) connection. Experience 4K Cinema resolutions along with rich bass and 7.1 surround sound while switching between both computers and sharing two USB 3.0 peripherals with the push of a button.

A Dual Cinema 4K Experience
Join two Cinema 4K HDMI monitors to your premium desktop or laptop to experience superior screen, image, and video quality. The Dual View HD KVMP delivers a Cinema 4K resolution standard of 4096 x 2160 at a frame rate of 60Hz.

Designed for professional film and video production industries, the 4-Port KVMP supports environments requiring cinematic graphics resolution. Superior quality is also ideal for applications in motion graphic design, animation, engineering, architecture, and media design.

Convenient Switching Methods
Switch and access four HDMI computers from the push-button front panel or hotkey combination on your keyboard. Utilize the latest in mouse port-switching functionality to change ports by simply clicking the wheel button on your 3-button USB mouse.

Expand to Utilize Up to Four 4K Monitors
Tackle large projects and double your desktop viewing space by adding a second 4-Port KVMP (GCS1944H). Expand your workstations to accommodate up to four 4K Cinema HDMI enabled monitors.

Smart Connectivity
Additional smart connectivity features turn your workstation into a convenient, easy-to-use powerhouse. The Power on Detection ensures automatic connection to the next powered-on computer. Expand your workstations to accommodate up to four 4K Cinema HDMI monitors. The built-in USB 3.0 ports provide connectivity speeds up to 5Gbps and compatibility with legacy USB 2.0 and 1.1 devices.

Video
HD type	4K Ultra HD
Video bandwidth	60 Hz
Maximum resolution	4096 x 2160 pixels
Ports & interfaces
Number of computers controlled	4
Keyboard port type	USB
USB connector type	USB Type-A, USB Type-B
Number of microphone inputs	6
Mouse port type	USB
Video port type	HDMI
Audio connections	Yes
Serial port type	RJ-45
HDMI version	2.0
Headphone outputs	6
HDMI ports quantity	10
HDCP	Yes
DC-in jack	Yes
Console USB ports quantity	2
Console ports	3.5mm headphone, 3.5mm mic, HDMI, USB A
Performance
Firmware upgradeable	Yes
Auto scan delay (min)	1 s
Auto scan delay (max)	99 s
HD type	4K Ultra HD
Video bandwidth	60 Hz
Hot-Plug support	Yes
Maximum resolution	4096 x 2160 pixels
Scan interval	1,5,99 s
HDCP	Yes
Design
Product colour	Black
Push button	Yes
LED indicators	Yes
Hot keys	Yes
Housing material	Metal
Display
Built-in display	No
Power
Power source	DC
Power consumption (typical)	4.42 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Weight & dimensions
Width	13.2" (335 mm)
Depth	6.34" (161 mm)
Height	1.73" (44 mm)
Weight	3.53 lbs (1.6 kg)
Package width	21.3" (540 mm)
Package depth	9.13" (232 mm)
Package height	4.72" (120 mm)
Package weight	9.04 lbs (4.1 kg)
Packaging data
Package width	21.3" (540 mm)
Package depth	9.13" (232 mm)
Package height	4.72" (120 mm)
Package weight	9.04 lbs (4.1 kg)
Other features
Push button	Yes
Hot keys	Yes
