When imaging precision cannot be compromised

When imaging precision and 24/7 operational reliability cannot be compromised, the 5th generation of NEC MultiSync P series presents best-in-class performance with an advanced feature set for mission-critical applications

Unparalleled clarity of detail and colour accuracy is achieved with 8K signal processing, wide colour gamut and the integrated NEC SpectraView engine controlling all visual parameters. Even in bright ambient light conditions, high brightness levels of 700 cd/m² combined with a high haze filter guarantees exceptional readability with no annoying reflections. Despite its slim, elegant profile, the quality build is robust for use in public spaces, with an all-metal chassis for fire-retardancy. Featuring NEC Open Modular Intelligence (OMI) slot-in technology, choose scalable computing power with Raspberry Pi Compute Module 4 or the more powerful Intel Smart Display Modules (Intel SDM) for tailor-made signage solutions.

For best visualisation in control rooms and production lines, for passenger information and wayfinding signage; the NEC P Series is trusted for safety and long-life, fit-for-purpose performance.

Display
Display diagonal	43"
Display resolution	3840 x 2160 pixels
Display brightness	700 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	8000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display diagonal (metric)	42.5" (108 cm)
Display number of colours	1.073 billion colors
Vertical scan range	23 - 76 Hz
Native aspect ratio	16:9
LED backlighting type	Edge-LED
Horizontal scan range	15 - 135 kHz
Display technology	IPS
Native refresh rate	60 Hz
Haze rate	28%
Ports & interfaces
Ethernet LAN	Yes
HDMI ports quantity	2
Ethernet LAN data rates	100 Mbit/s
USB port	Yes
Audio (L/R) out	1
Ethernet LAN (RJ-45) ports	1
USB version	2.0
USB ports quantity	3
DisplayPorts quantity	2
Design
Product design	Digital signage flat panel
Product colour	Black
VESA mounting	Yes
Panel mounting interface	300 x 300 mm
Placement supported	Indoor
Orientation	Horizontal/Vertical
Bezel width (top)	0.433" (1.1 cm)
Bezel width (side)	0.433" (1.1 cm)
Bezel width (bottom)	0.614" (1.56 cm)
Performance
Purpose	Universal
Operating hours (hours/days)	24/7
International Protection (IP) code	IP5X, IP2X
Picture-in-Picture	Yes
HDCP	Yes
Ambient light sensor	Yes
Power
Power consumption (typical)	90 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	87 kWh
Energy consumption (HDR) per 1000 hours	87 kWh
Weight & dimensions
Display width	38.1" (968.2 mm)
Display depth	2.64" (67.1 mm)
Display height	22.1" (561 mm)
Display weight	40.8 lbs (18.5 kg)
Packaging data
Package width	44.1" (1120 mm)
Package depth	7.99" (203 mm)
Package height	27.6" (700 mm)
Package weight	50.7 lbs (23 kg)
Remote control included	Yes
Cables included	AC, HDMI
Batteries included	Yes
Packaging content
Remote control included	Yes
Cables included	AC, HDMI
Batteries included	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 90%
Network
Ethernet LAN	Yes
Ethernet LAN data rates	100 Mbit/s
Sensors
Ambient light sensor	Yes
Logistics data
Harmonized System (HS) code	85285210
Features
Harmonized System (HS) code	85285210
Technical details
LED backlighting type	Edge-LED
Ambient light sensor	Yes
Other features
Display technology	IPS
Bezel width (top)	0.433" (1.1 cm)
Bezel width (side)	0.433" (1.1 cm)
Bezel width (bottom)	0.614" (1.56 cm)
