The ViewSonic TD2223 is a 22” IR touch display designed for intuitive multi-touch use. Infrared (IR) touchscreen can detect up to 10 points of contact compared to optical touchscreens and can be operated by a stylus, fingers and gloved hands. The multi-touch input is more accurate, and the display is faster. Coupled with an adjustable tilt, you can easily interact with the TD2223 at an ideal position. This monitor features Full HD resolution to give you clear images and is built with scratch-resistant 7H hardness screen to surface damage. To support your work, the TD2223 is equipped with VGA, HDMI, DVI and USB connectivity.

Intuitive Multi-touch Experience
An infrared touchscreen that can detect up to 10 points of contact under Windows compared to optical touchscreens, the TD2223 delivers an intuitive multi-touch experience with every tap, pinch, and swipe.

Operating System Support
This monitor supports the main operating systems being Windows, macOS, Android, Chrome OS, Linux and Raspberry Pi.

Simple and Safer Way to Interact
This monitor can be operated by stylus and gloved hands, which improves hygiene and is effective for selection, dragging, and drawing. What’s more, there is a magnetic pen placeholder on the base.

Anti-scratch Touchscreen
With a built-in 7H hardness screen, it’s resistant to surface damage caused by sharp objects.

Adjustable Tilt
This monitor includes an adjustable tilt, which allows you to easily tilt back up to 40-degrees, making it a good fit for anyone.

Clear Images
This monitor features Full HD 1920x1080 resolution to benefit you with greater image details and more displayable on-screen contents.

Dual Integrated Speakers
With built-in 2-watt speakers, this monitor provides you a better audiovisual experience.

Enhanced Viewing Comfort
This monitor is built with Flicker-Free technology and a Blue Light Filter to reduce eye fatigue after a long day of use.

Display
Display diagonal	21.5"
Response time	5 ms
Display resolution	1920 x 1080 pixels
Display technology	LED
Screen shape	Flat
Display number of colours	16.78 million colors
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	20000000:1
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Pixel pitch	0.00976 x 0.00976" (0.248 x 0.248 mm)
Horizontal scan range	24 - 82 kHz
Vertical scan range	50 - 75 Hz
HD type	Full HD
Touchscreen type	Multi-user
Touchscreen	Yes
Number of simultaneous touchpoints	10
Panel type	TN
Touch technology	Multi-touch
Touchscreen technology	Infrared
Display brightness	250 cd/m²
Performance
AMD FreeSync	No
NVIDIA G-SYNC	No
Multimedia
Built-in speaker(s)	Yes
Built-in camera	No
Number of speakers	2
RMS rated power	4 W
Built-in microphone	No
Design
Product colour	Black
Certification	cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BSMI, RCM, GEMS, PSE, CCC, China RoHS, China Energy Label, CECP
Glass thickness	0.0787" (2 mm)
Ports & interfaces
Built-in USB hub	Yes
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	2
VGA (D-Sub) ports quantity	1
DVI port	Yes
DVI-D ports quantity	1
HDMI ports quantity	1
Headphone outputs	1
Microphone in	Yes
Headphone out	Yes
HDMI	Yes
HDMI version	1.4
Ergonomics
Wall mountable	Yes
Cable lock slot	Yes
Panel mounting interface	100 x 100 mm
Tilt angle range	22 - 38°
Cable lock slot type	Kensington
Tilt adjustment	Yes
Power
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	14 W
Power consumption (standby)	0.5 W
Power consumption (typical)	12.5 W
Power supply type	AC
Energy efficiency class (SDR)	E
Energy consumption (SDR) per 1000 hours	14 kWh
European Product Registry for Energy Labelling (EPREL) code	368718
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 90%
Weight & dimensions
Width (with stand)	20.5" (521 mm)
Depth (with stand)	3.98" (101 mm)
Height (with stand)	13.1" (334 mm)
Width (without stand)	20.5" (521 mm)
Height (without stand)	12.5" (318 mm)
Depth (without stand)	2.4" (61 mm)
Weight (with stand)	9.92 lbs (4.5 kg)
Weight (without stand)	8.6 lbs (3.9 kg)
Package width	22.8" (580 mm)
Package depth	6.46" (164 mm)
Package height	15.9" (405 mm)
Package weight	13.2 lbs (6 kg)
Packaging data
Package width	22.8" (580 mm)
Package depth	6.46" (164 mm)
Package height	15.9" (405 mm)
Package weight	13.2 lbs (6 kg)
Stand included	Yes
Cables included	AC, Audio (3.5mm), HDMI, USB Type-A to USB Type-B
Packaging content
Stand included	Yes
Cables included	AC, Audio (3.5mm), HDMI, USB Type-A to USB Type-B
Sustainability
European Product Registry for Energy Labelling (EPREL) code	368718
Sustainability certificates	ENERGY STAR
Technical details
Sustainability certificates	ENERGY STAR
Compliance certificates	REACH, RoHS
Power supply type	AC
Weight (with stand)	9.92 lbs (4.5 kg)
Touchscreen type	Multi-user
Touchscreen	Yes
Number of simultaneous touchpoints	10
Other features
Certification	cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BSMI, RCM, GEMS, PSE, CCC, China RoHS, China Energy Label, CECP
Compliance certificates	REACH, RoHS
Power consumption (max)	14 W
Width (without stand)	20.5" (521 mm)
Height (without stand)	12.5" (318 mm)
HDMI	Yes
Depth (without stand)	2.4" (61 mm)
Power supply type	AC
Touchscreen type	Multi-user
Touchscreen	Yes
Number of simultaneous touchpoints	10
Certificates
Certification	cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BSMI, RCM, GEMS, PSE, CCC, China RoHS, China Energy Label, CECP
Logistics data
Harmonized System (HS) code	85285210
