The OR1500LCDRT2U has a capacity of 1500VA/900Watts, eight (8) battery and surge protected NEMA 5-15R receptacles. This UPS has four (4) maintenance-free, user-replaceable 12V/7Ah batteries. The UPS offers options for connectivity via one (1) HID USB, two (2) DB9 serial and a SNMP card slot (optional RMCARD202 & RMCARD203). Protection for phone/network (RJ11/RJ45) and cable/coax (RG6) is included. EMI/RFI filters increase the immunity of the load to noise disturbances. Its design allows it to be either freestanding or rack-mounted (2U). The rotatable front LCD panel displays all major UPS vitals for ease of use.
The OR1500LCDRT2U UPS system is ENERGY STAR® qualified with patented GreenPower UPS™ Bypass circuitry to save on energy costs by reducing energy consumption and heat buildup.
This UPS unit incorporates microprocessor-based digital control and includes PowerPanel® Business Edition providing the user unsurpassed flexibility and control. A Three-Year Warranty ensures that this UPS has passed our highest quality standards in design, assembly, material or workmanship and further protection is offered by a $300,000 Connected Equipment Guarantee.
CyberPower OR1500LCDRT2U uninterruptible power supply (UPS) Line-Interactive 1.5 kVA 900 W 8 AC outlet(s)
Part number
OR1500LCDRT2U
$722.26 CAD
900W, NEMA 5-15R, 4ms, 1840 Joules, RJ-45, 21953g, Black
Description
The CyberPower Smart App Intelligent LCD OR1500LCDRT2U uninterruptible power supply (UPS) is designed to protect office servers, corporate and departmental networks, and network-based appliances such as internetworking hardware, telecom equipment and high-end workstations. Its automatic voltage regulation (AVR) technology delivers a consistent and clean AC power, protecting connected equipment and preventing costly business interruptions.The OR1500LCDRT2U has a capacity of 1500VA/900Watts, eight (8) battery and surge protected NEMA 5-15R receptacles. This UPS has four (4) maintenance-free, user-replaceable 12V/7Ah batteries. The UPS offers options for connectivity via one (1) HID USB, two (2) DB9 serial and a SNMP card slot (optional RMCARD202 & RMCARD203). Protection for phone/network (RJ11/RJ45) and cable/coax (RG6) is included. EMI/RFI filters increase the immunity of the load to noise disturbances. Its design allows it to be either freestanding or rack-mounted (2U). The rotatable front LCD panel displays all major UPS vitals for ease of use.
The OR1500LCDRT2U UPS system is ENERGY STAR® qualified with patented GreenPower UPS™ Bypass circuitry to save on energy costs by reducing energy consumption and heat buildup.
This UPS unit incorporates microprocessor-based digital control and includes PowerPanel® Business Edition providing the user unsurpassed flexibility and control. A Three-Year Warranty ensures that this UPS has passed our highest quality standards in design, assembly, material or workmanship and further protection is offered by a $300,000 Connected Equipment Guarantee.
Specifications
| Power | |
|---|---|
| Output power capacity | 1.5 kVA |
| Output power | 900 W |
| Input operation voltage (min) | 90 V |
| Input operation voltage (max) | 140 V |
| Output operation voltage (max) | 120 V |
| Surge energy rating | 1840 J |
| Input frequency | 47/63 Hz |
| Ports & interfaces | |
| Cable length | 7.87" (0.2 m) |
| AC outlets quantity | 8 AC outlet(s) |
| AC outlet types | NEMA 5–15R |
| Power plug | NEMA 5-15P |
| Serial ports quantity | 2 |
| Modem (RJ-11) ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| UPS topology | Line-Interactive |
| Response time | 4 ms |
| Surge protection | Yes |
| Surge protection features | Network, Telephone |
| Automatic Voltage Regulation (AVR) | Yes |
| LED indicators | Yes |
| Features | |
| UPS topology | Line-Interactive |
| Output power capacity | 1.5 kVA |
| Response time | 4 ms |
| Output power | 900 W |
| Input operation voltage (min) | 90 V |
| Input operation voltage (max) | 140 V |
| Output operation voltage (max) | 120 V |
| Surge energy rating | 1840 J |
| Surge protection | Yes |
| Surge protection features | Network, Telephone |
| Automatic Voltage Regulation (AVR) | Yes |
| Input frequency | 47/63 Hz |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Number of batteries supported | 4 |
| Battery recharge time | 8 h |
| Typical backup time at half load | 18 min |
| Typical backup time at full load | 6 min |
| Design | |
| Form factor | Rackmount/Tower |
| Rack capacity | 2U |
| Product colour | Black |
| Cable length | 7.87" (0.2 m) |
| Cooling type | Passive |
| LED indicators | Yes |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Cooling | |
| Cooling type | Passive |
| Weight & dimensions | |
| Width | 17.2" (438.1 mm) |
| Depth | 15.7" (400 mm) |
| Height | 3.5" (88.9 mm) |
| Weight | 48.5 lbs (22 kg) |
