Kensington SD5600T Thunderbolt™ 3 and USB-C Dual 4K Hybrid Docking Station - 100W PD – Win/Mac
256.13 CAD
Skip to product information
In stock
Kensington SD5600T Thunderbolt™ 3 and USB-C Dual 4K Hybrid Docking Station - 100W PD – Win/Mac
Part number
K34009NA
256.13 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
1.743 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
- Best for: Thunderbolt 3 and USB-C laptops and monitors that support up to dual 4K
- Connection technology: Thunderbolt 3 and USB-C (cross platform compatibility)
- Power Delivery: Supports USB-C PD 3.0 up to 100W (96W certified)
- Compatibility: Windows 10 or above, macOS 10.14 or above
- No. of monitors supported: 2
- Video ports: 2 x HDMI v2.0 and 2 x DisplayPort 1.2
- Maximum resolution supported: Thunderbolt 3 – single or dual monitors: 4K (3840 x 2160 @ 60Hz) // USB-C Alt Mode HBR3 – single monitor: 4K @ 60Hz or dual monitors: 1440p @ 60Hz // USB-C Alt Mode HBR2 – single monitor: 4K @ 30Hz or dual monitors: 1080p @ 60Hz
- Plug & play: Plug & play installation, though installation of Kensington DockWorks™ software is recommended for the best connection, performance and security from your Kensington universal docking station
- System requirements: Compatible with laptops equipped with Thunderbolt 3 and USB-C ports supporting Alt Mode. Supports up to 40Gbps total bandwidth for Thunderbolt 3 laptops, and up to 10Gbps for USB-C laptops
- Warranty: 3 Years
- Original Apple M1 - While this docking station will work with the original M1 MacBook, only a single video output is supported. For multi-monitor support on your original M1 MacBook, see our Hybrid USB-C DisplayLink docking stations (ex: SD4700P, SD4750P, SD4780P, SD4900P, etc.) or USB-A DisplayLink adapters (DisplayPort K33989, HDMI K33988, DVI-I K33974). NOTE: Newer Apple devices (M1 Max and M1 Pro, etc.) are not impacted and support multiple monitors without any issues on Thunderbolt docking stations
- Optimised for your Windows 11 docking station needs, including support for Snap Layouts and Snap Groups
Kensington SD5600T Thunderbolt™ 3 and USB-C Dual 4K Hybrid Docking Station - 100W PD – Win/Mac. Connectivity technology: Wired, Host interface: Thunderbolt 3, USB Power Delivery up to: 100 W. Ethernet LAN data rates: 10,100,1000 Mbit/s. Product color: Black, Silver, Compatible memory cards: MicroSD (TransFlash), SD, Data transfer rate: 40 Gbit/s. Power source type: DC, AC input voltage: 100 - 240 V, Input current: 1.8 A. Width: 7.76" (197 mm), Depth: 4.09" (104 mm), Height: 1.45" (36.8 mm)
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wired |
| Host interface | Thunderbolt 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio output | 3.5 mm |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 2 |
| DC-in jack | Yes |
| Combo headphone/mic port | Yes |
| USB Power Delivery | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| DisplayPort version | 1.2 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Product colour | Black, Silver |
| Card reader integrated | Yes |
| Brand compatibility | Universal |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Cable lock slot | Yes |
| Country of origin | Thailand |
| Plug and Play | Yes |
| Data transfer rate | 40 Gbit/s |
| Certification | FCC, IC, CE, RCM, VCCI, CB, RoHS, ACCO RSL |
| Cable lock slot type | Kensington |
| HD type | 4K Ultra HD |
| VESA mounting | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Aluminum, Metal, Polycarbonate (PC) |
| Storage | |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Power | |
| Power source type | DC |
| AC input voltage | 100 - 240 V |
| Input current | 1.8 A |
| Power consumption (max) | 170 W |
| Output voltage | 20 V |
| Output current | 8.5 A |
| Software | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -18 - 60 °C |
| Weight & dimensions | |
| Width | 7.76" (197 mm) |
| Depth | 4.09" (104 mm) |
| Height | 1.45" (36.8 mm) |
| Weight | 29.5 oz (835 g) |
| Package width | 9.96" (253 mm) |
| Package depth | 5.98" (152 mm) |
| Package height | 3.58" (91 mm) |
| Package weight | 3.84 lbs (1.74 kg) |
| Design | |
| Product colour | Black, Silver |
| Cable lock slot | Yes |
| Country of origin | Thailand |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Certification | FCC, IC, CE, RCM, VCCI, CB, RoHS, ACCO RSL |
| Cable lock slot type | Kensington |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 9.96" (253 mm) |
| Package depth | 5.98" (152 mm) |
| Package height | 3.58" (91 mm) |
| Package weight | 3.84 lbs (1.74 kg) |
| Packaging content | |
| User guide | Yes |
| Stand included | Yes |
| AC adapter included | Yes |
| Warranty card | Yes |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| User guide | Yes |
