Elo Touch Solutions ET1093L 10.1" LCD 350 cd/m² Black Touchscreen
579.06 CAD
Skip to product information
Out of stock
Elo Touch Solutions ET1093L 10.1" LCD 350 cd/m² Black Touchscreen
Part number
E321195
Sale price
579.06 CAD
Regular price
617.87 CAD
Taxes and shipping calculated at checkout.
Save
38.81 CAD
Off
6%
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
2.6 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
The Elo 1093L 10.1-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions thanks to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact display is designed for touch, with proven Elo expertise and reliability built in. The 1093L provides stable, drift-free operation with outstanding image clarity and light transmission—for accurate touch responses and vivid images. Instantly grabbing and holding users’ attention, the open-frame touchscreen is perfect for kiosks, casino and amusement, retail self-service, and industrial automation environments.
Easily integrated.
The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected.
Touch ready.
This seamless, zero-bezel, 10-inch multi-touch display is available with our latest TouchPro™ PCAP two-glass solution (2GS) technology that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality—both modes support single or dual latex gloves as well as cloth gloves.
Commercial-grade.
The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution, with touch integrated from the start. Using our touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life-testing processes. All our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.
Other features.
- 10-touch TouchPro projected capacitive (PCAP) with two-touch thru-glass capabilities
- Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing
- Easy to integrate with flush mounting brackets on all 4 sides and rear 75 mm VESA mount
- Display Port and VGA video interfaces
Easily integrated.
The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected.
Touch ready.
This seamless, zero-bezel, 10-inch multi-touch display is available with our latest TouchPro™ PCAP two-glass solution (2GS) technology that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality—both modes support single or dual latex gloves as well as cloth gloves.
Commercial-grade.
The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution, with touch integrated from the start. Using our touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life-testing processes. All our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.
Other features.
- 10-touch TouchPro projected capacitive (PCAP) with two-touch thru-glass capabilities
- Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing
- Easy to integrate with flush mounting brackets on all 4 sides and rear 75 mm VESA mount
- Display Port and VGA video interfaces
| Display | |
|---|---|
| Display diagonal | 10.1" |
| Display resolution | 1280 x 800 pixels |
| Display brightness | 350 cd/m² |
| Response time | 25 ms |
| Contrast ratio (typical) | 800:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 170° |
| Display number of colours | 262144 colors |
| Touchscreen | Yes |
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 800 |
| Panel type | TFT |
| Display technology | LCD |
| Touchscreen technology | Projected capacitive system |
| Ports & interfaces | |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Design | |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 75 x 75 mm |
| Screen shape | Flat |
| Performance | |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Number of OSD languages | 8 |
| Mean time between failures (MTBF) | 50000 h |
| Power | |
| Power consumption (typical) | 6.1 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (off) | 0.5 W |
| Packaging data | |
| Package width | 13.2" (336 mm) |
| Package depth | 6.89" (175 mm) |
| Package height | 10.3" (262 mm) |
| Package weight | 5.73 lbs (2.6 kg) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 95% |
| Operating altitude | 0 - 144015.7" (0 - 3658 m) |
| Non-operating altitude | 144015.7 - 480000" (3658 - 12192 m) |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Features | |
| Harmonized System (HS) code | 85285210 |
| Wall mountable | Yes |
| Technical details | |
| Power supply type | AC/DC |
| Weight (without stand) | 2.65 lbs (1.2 kg) |
| Panel type | TFT |
| Height (without stand) | 7.03" (178.5 mm) |
| Display viewable area (HxV) | 8.54 x 5.34" (217 x 135.6 mm) |
| Depth (without stand) | 1.45" (36.9 mm) |
| Other features | |
| Power supply type | AC/DC |
| Weight (without stand) | 2.65 lbs (1.2 kg) |
| Power consumption (PowerSave) | 0.7 W |
| Panel type | TFT |
| Operating altitude | 0 - 144015.7" (0 - 3658 m) |
| Non-operating altitude | 144015.7 - 480000" (3658 - 12192 m) |
| Mean time between failures (MTBF) | 50000 h |
| Height (without stand) | 7.03" (178.5 mm) |
| Display viewable area (HxV) | 8.54 x 5.34" (217 x 135.6 mm) |
| Display technology | LCD |
| Digital vertical frequency | 50 - 75 Hz |
| Digital horizontal frequency | 30 - 60 kHz |
| Depth (without stand) | 1.45" (36.9 mm) |
| Backlight type | LED |
| Aspect ratio | 16:10 |
