EloPOS™ System
Modern. Modular. Made for Retail.
The versatile EloPOS System combines modern aesthetics, modular flexibility and commercial-grade reliability. Purpose-built for point of sale, EloPOS offers a 15.6-inch touchscreen display, choice of Intel’s 8th generation processors and an integrated expansion hub to connect the peripherals you need - whether a customer facing display, payment reader, printer, cash drawer, barcode scanner or scale. From traditional POS to self-service applications, EloPOS delivers the durability needed to survive continuous public use and is backed by Elo’s standard 3-year warranty.

Interactive Points of Sale
The EloPOS System is designed to offer flexibility across environments. Whether you need a fixed-lane point of sale system or a self-order solution, EloPOS can help ensure that every touch delivers the experience your employees need and your customers expect.

Connections. Connections. Connections.
The expansion hub allows you to connect all of the POS peripheral support you need. From cash drawers and printers to barcode scanners and payment devices — there is connectivity to cover it all. With two models, the hub is integrated into the base of the EloPOS stand or mounted to the back of the display for pole and wall mount configurations.

Configure Your Solution
EloPOS is designed with the flexibility to be mounted however you desire. With a standard VESA mounting system, and optional pole and self-service stands, EloPOS offers the modularity you need to create the solution you want. From POS terminals to self-service checkout, the EloPOS can be configured to deliver maximum impact.

Add a Customer-Facing
Display with Ease The EloPOS System includes USB-C connectivity, allowing you to easily connect a 1302L customer-facing display - providing touch, data and power with just one cable. By reducing the number of cables required for setup from 3 to 1, installation and servicing is a breeze.

Elo Edge Connect™ Lets You do More!
Built with versatility in mind, Elo Edge Connect offers a wide assortment of peripheral options. Whether for point of sale, endless aisle or self-order applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!

Windows or Linux. You Choose.
EloPOS utilizes the reliability-tested performance and security of Intel 8th Generation processors, integrated Trusted Platform Modules, Intel vPro™ and the Windows 10 operating system. For added flexibility, the EloPOS offers models with no OS - all pretested with Linux SuSE, Ubuntu and Red Hat operating systems, allowing businesses to get the solution best-suited for them.

Retail-Hardened
Rigorously tested and backed by a three-year warranty, the EloPOS System delivers superior quality and reliability. The splash-proof housing and rugged retail-hardened design can easily withstand the adverse conditions associated with most commercial environments. Additional one and two-year warranty extensions are available as well as EloCare options - making EloPOS the ideal product for point of sale applications.

Display
Display number of colours	262144 colors
Viewing angle, vertical	160°
Viewing angle, horizontal	160°
Touchscreen technology	Capacitive
Touchscreen	Yes
Response time	25 ms
Effective viewing area	13.6 x 7.62" (344.2 x 193.5 mm)
Display resolution	1920 x 1080 pixels
Display diagonal	15.6"
Display brightness	255 cd/m²
Contrast ratio (typical)	700:1
Aspect ratio	16:9
Display type	LED
Processor
Processor frequency	3.5 GHz
Processor family	Intel® Core™ i5
Processor model	i5-8500T
Processor cache	9 MB
Motherboard chipset	Intel Q370
Processor manufacturer	Intel
Processor generation	8th gen Intel® Core™ i5
Memory
Internal memory	8 GB
Internal memory type	DDR4-SDRAM
Number of memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	2666 MHz
Storage
SSD interface	SATA
SSD capacity	256 GB
Storage media	SSD
SSD form factor	M.2
Flash memory	2666 GB
Graphics
Graphics card manufacturer	Intel
Graphics card	UHD Graphics 630
Multimedia
Built-in speaker(s)	Yes
Number of speakers	2
Network
Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi	Yes
Bluetooth	Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports	3
USB 2.0 ports quantity	2
Powered USB	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Design
Product colour	Black
Performance
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Software
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Windows operating systems supported	Windows 10 IoT Enterprise
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	76 W
Operational conditions
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80%
Ergonomics
VESA mounting	Yes
Panel mounting interface	75 x 75 mm
Mean time between failures (MTBF)	50000 h
Weight & dimensions
Width	15.2" (386.2 mm)
Depth	2.89" (73.3 mm)
Height	9.8" (248.9 mm)
Weight	6.39 lbs (2.9 kg)
Package width	18.2" (462 mm)
Package depth	8.5" (216 mm)
Package height	13.6" (346 mm)
Package weight	10.8 lbs (4.9 kg)
Packaging data
Package width	18.2" (462 mm)
Package depth	8.5" (216 mm)
Package height	13.6" (346 mm)
Package weight	10.8 lbs (4.9 kg)
Quantity per pack	1 pc(s)
Packaging content
Cables included	AC
Technical details
Quantity per pack	1 pc(s)
