APC AP7822B power distribution unit (PDU) 16 AC outlet(s) 2U Black
1,290.74 CAD
Skip to product information
Out of stock
APC AP7822B power distribution unit (PDU) 16 AC outlet(s) 2U Black
Part number
AP7822B
1,290.74 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
5.41 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
APC Metered Rack PDUs offer resilient power distribution and actively measure, display, and log amperage to support real-time monitoring and historical reporting. This PDU remote monitoring and user-defined alarms to help prevent circuit overloads that can cause accidental power loss to critical equipment. The historical reporting enables users to optimize energy use and plan for capacity with confidence. This PDU can operate at up to 60 degrees Celsius and can be accessed, configured, and managed remotely via EcoStruxure IT, Web, SNMP and Command Line Interface. Power is supplied to the PDU at 200-230 volts via IEC 309 plug with a 3.6m (11 ft) cord while power comes out at 230 volts through (36) IEC 320 C13 and (6) IEC 320 C19 outlets. As a Green Premium product, this unit comes with a verified product environment profile, including carbon footprint, scope 3 emissions and end of life instructions.
| Design | |
|---|---|
| PDU types | Metered |
| Mounting | Horizontal/Vertical |
| On/off switch | Yes |
| Type | Single-phase |
| Product colour | Black |
| Certification | C-tick, CE, FCC 15 A, GOST, ICES-003, IRAM, MIC, VDE, VCCI |
| Rack capacity | 2U |
| Ports & interfaces | |
| Power plug | IEC309 |
| AC outlets quantity | 16 AC outlet(s) |
| AC outlet types | C13 coupler, C19 coupler |
| Input connection type | IEC 309 32A 2P+E |
| Output connections | 12 x C13 4 x C19 |
| Features | |
| LED indicators | Yes |
| Cable length | 144.1" (3.66 m) |
| Certification | C-tick, CE, FCC 15 A, GOST, ICES-003, IRAM, MIC, VDE, VCCI |
| Management features | |
| Monitoring | Current, Power, Voltage |
| Ergonomics | |
| LED indicators | Yes |
| Cable length | 144.1" (3.66 m) |
| Power | |
| Nominal input voltage | 208-230 V |
| Maximum power | 7680 W |
| Maximum current | 32 A |
| Load capacity | 7680 VA |
| Maximum input current per phase | 32 A |
| Maximum total current draw per phase | 32 A |
| Power protection features | Overload |
| AC input frequency | 50 - 60 Hz |
| Certificates | |
| Certification | C-tick, CE, FCC 15 A, GOST, ICES-003, IRAM, MIC, VDE, VCCI |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 45 °C |
| Storage temperature (T-T) | -25 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Weight | 7.41 lbs (3.36 kg) |
| Width | 17.5" (444 mm) |
| Depth | 4.41" (112 mm) |
| Height | 3.46" (88 mm) |
| Package width | 20" (508 mm) |
| Package depth | 14.5" (368 mm) |
| Package height | 5.51" (140 mm) |
| Package weight | 11.9 lbs (5.41 kg) |
| Packaging data | |
| Package width | 20" (508 mm) |
| Package depth | 14.5" (368 mm) |
| Package height | 5.51" (140 mm) |
| Package weight | 11.9 lbs (5.41 kg) |
| Technical details | |
| Total carbon footprint (kg of CO2e) | 8952.07 |
| Compliance certificates | RoHS |
| Logistics data | |
| Total carbon footprint (kg of CO2e) | 8952.07 |
