Broadcast your HDMI signal to multiple locations throughout your site, using your existing network infrastructure

The HDMI® over IP receiver works with the HDMI over IP Extender (ST12MHDLNHK) to distribute HDMI to an additional remote display. You can add multiple receivers (each sold separately) to easily distribute HDMI to multiple locations.

Customize your video distribution with a scalable solution

With additional receivers, you can scale your HDMI over IP kit installation to suit your needs. In a point-to-multipoint setup, you can route HDMI over IP to as many receivers as you need. For additional scalability, you can combine up to 99 different kits (ST12MHDLNHK) to create a multipoint-to-multipoint setup, where you can route different HDMI source signals to different displays. Mounting hardware and IR extenders are included for each transmitter and receiver to ensure tidy, professional installation and hassle-free remote operation.

Get brilliant video at HD 1080p

The receiver maintains your HD video signal, supporting resolutions up to 1080p. Maintaining your HD quality over IP makes it easy to distribute dynamic digital signage throughout your site to attract and engage customers.

Save your network bandwidth with video compression

Unlike some video-over-IP solutions that consume your bandwidth, this HDMI over IP solution uses video compression to distribute high-quality HDMI over your local area network, with minimal bandwidth requirements. Extending your HDMI using compression saves your network resources, avoiding the hassle of a separate video network.

The ST12MHDLNHR is backed by a 2-year StarTech.com warranty and free lifetime technical support.

The StarTech.com Advantage

Features
Type	AV receiver
Maximum resolution	1920 x 1200 pixels
Cable types supported	Cat5e
Audio output channels	2.0 channels
Rack mounting	Yes
Daisy chain	Yes
Maximum refresh rate	60 Hz
Maximum transfer distance	590.6" (15 m)
Supported video modes	1080p
Material	Aluminum
LED indicators	Status
Cable length	598.4" (15.2 m)
Product colour	Black
Certification	CE, REACH, FCC, TAA
Rubber feet	Yes
Ports & interfaces
RJ-45 input ports	1
USB ports quantity	1
Number of HDMI outputs	1
USB connector type	Mini-USB B
Ethernet LAN	Yes
Audio output	1
Connectivity technology	Wired
Power
Input current	0.3 A
Output current	1 A
AC input voltage	100 - 240 V
External power adapter	Yes
Operating voltage	5 V
Operational conditions
Storage relative humidity (H-H)	0 - 80%
Operating relative humidity (H-H)	0 - 80%
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Weight & dimensions
Weight	7.51 oz (213 g)
Width	3.82" (97 mm)
Height	0.945" (24 mm)
Depth	5.12" (130 mm)
Packaging data
Package width	6.1" (155 mm)
Package weight	28.2 oz (800 g)
Package height	2.56" (65 mm)
Package depth	9.25" (235 mm)
Packaging content
IR receiver included	Yes
Mounting kit	Yes
Manual	Yes
Cables included	LAN (RJ-45), Serial, USB
AC adapter included	Yes
Included power plug types	ANZ, EU, NA, UK
Technical details
Compliance certificates	RoHS
Logistics data
Master (outer) case width	12.8" (325 mm)
Master (outer) case length	16.1" (410 mm)
Master (outer) case height	10.4" (265 mm)
Products per master (outer) case	12 pc(s)
