22" Signage with More Utility for Commercial Space
22SM3G delivers information and performs guide with more effective ways in various commercial space, which provides more convenient solution thanks to its upgraded webOS platform.

High Performance SoC with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.

Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players.

A Wide Range of Interfaces
Through its diverse interfaces, users can connect the display with various sources for optimal use. Also, the failover function supports users preparing backup sources in case an unexpected error occurs.

USB Plug & Play
22SM3G supports USB Plug & Play feature, so users can easily set content playback using a USB.

Remote Monitoring and Control
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple 22SM3G displays in different locations in real-time. It is available on internet-connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere.

Real-time Care Service with LG Signage365Care
The maintenance gets easier and faster with the optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring stable operation of the client’s business.

Display
Display diagonal	21.5"
Display resolution	1920 x 1080 pixels
Display brightness	250 cd/m²
HD type	Full HD
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	400000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display diagonal (metric)	22" (55.9 cm)
Touchscreen	No
Native aspect ratio	16:9
Display technology	IPS
Ports & interfaces
Ethernet LAN	Yes
HDMI ports quantity	2
DVI port	No
USB port	Yes
Audio (L/R) in	1
Ethernet LAN (RJ-45) ports	1
RS-232 interface	Yes
Wi-Fi	Yes
USB version	2.0
USB ports quantity	1
RS-232C	Yes
DisplayPorts quantity	0
Audio
Number of built-in speakers	2
RMS rated power	2 W
Built-in speaker(s)	Yes
Design
Product design	Digital signage flat panel
Product colour	Black
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Orientation	Horizontal
Certification	CB, NRTL, EMC, FCC Class "A", CE, ErP
Performance
Purpose	Universal
Operating hours (hours/days)	16/7
Wi-Fi	Yes
Power
Power consumption (typical)	33 W
Power consumption (standby)	30 W
Heat dissipation	7.89 BTU/h
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	1 W
Power consumption (off)	0.5 W
Computer system
Computer system	No
Internal memory	4 GB
Processor cores	4
Built-in processor	Yes
Weight & dimensions
Width	20.1" (510.3 mm)
Depth	2.12" (53.8 mm)
Height	11.9" (302.1 mm)
Weight	7.36 lbs (3.34 kg)
Packaging data
Package width	22.2" (565 mm)
Package depth	4.06" (103 mm)
Package height	14.1" (357 mm)
Package weight	7.72 lbs (3.5 kg)
Remote control included	Yes
Mounting kit	Yes
Cables included	AC
Batteries included	Yes
Packaging content
Remote control included	Yes
Mounting kit	Yes
Cables included	AC
Batteries included	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 85%
Certificates
Certification	CB, NRTL, EMC, FCC Class "A", CE, ErP
Thin Client
Internal memory	4 GB
Logistics data
Harmonized System (HS) code	85285210
Features
Harmonized System (HS) code	85285210
Other features
Wi-Fi	Yes
Display technology	IPS
