iogear GHSW8481 video splitter HDMI
248.11 CAD
Skip to product information
Out of stock
iogear GHSW8481 video splitter HDMI
Part number
GHSW8481
248.11 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
2.585 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
- Connect and switch between 8 HDMI sources on 1 HDMI display
- True 4K resolutions to 4096 x 2160 @ 60Hz (4:4:4)
- Distribute uncompressed audio formats
- Flexible control via push-button, IR remote & RS-232 serial control
- Bi-directional RS-232 support for universal remotes & touch panels
- Auto-switch mode detects & selects new HDMI port connections
- Supports high-speed data rates up to 18 Gbps
- No-slip locking power supply mechanism
- cascade 3-levels
- HDMI 2.0 and HDCP 2.2 compliant
- CEC compliant
- Plug-n-Play
8-Port True 4K Switch With HDMI®
The IOGEAR 8-Port True 4K Switch with HDMI connection offers smooth, quick switching between eight HDMI video sources such as a computer, Blu-ray or media player, and cable or satellite receivers and a single HDMI display. Send crystal clear, Cinema 4K video reaching true 4K resolutions to 4096 x 2160 @ 60Hz with 4:4:4 Chroma subsampling, High Dynamic Range (HDR) and uncompressed audio for any variety of uses including home theater, in lobbies and conference rooms and for digital signage.
Flexible Source Switching
Easily switch between each source automatically or manually. Utilize one of three Switch Modes and auto-cycle through your sources with smooth video transitions to display a variety of content. Manually switch between sources with the included IR remote control, program a universal remote via the RS-232 serial interface or select a source via front panel push-buttons in settings where a remote control is not needed.
True 4K Video Quality
Enjoy clear, superior Cinema 4K video quality with true 4K resolutions to 4096 x 2160 @ 60Hz (4:4:4) and HDR support to the display.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
The IOGEAR 8-Port True 4K Switch with HDMI connection offers smooth, quick switching between eight HDMI video sources such as a computer, Blu-ray or media player, and cable or satellite receivers and a single HDMI display. Send crystal clear, Cinema 4K video reaching true 4K resolutions to 4096 x 2160 @ 60Hz with 4:4:4 Chroma subsampling, High Dynamic Range (HDR) and uncompressed audio for any variety of uses including home theater, in lobbies and conference rooms and for digital signage.
Flexible Source Switching
Easily switch between each source automatically or manually. Utilize one of three Switch Modes and auto-cycle through your sources with smooth video transitions to display a variety of content. Manually switch between sources with the included IR remote control, program a universal remote via the RS-232 serial interface or select a source via front panel push-buttons in settings where a remote control is not needed.
True 4K Video Quality
Enjoy clear, superior Cinema 4K video quality with true 4K resolutions to 4096 x 2160 @ 60Hz (4:4:4) and HDR support to the display.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
| Ports & interfaces | |
|---|---|
| Video ports quantity | 8 |
| Video port type | HDMI |
| Video out | HDMI |
| HDMI version | 2.0 |
| DC-in jack | Yes |
| Features | |
| Supported graphics resolutions | 4096 x 2160 |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| Plug and Play | Yes |
| Maximum refresh rate | 60 Hz |
| Remote control included | Yes |
| Certification | CEC |
| Power | |
| Output voltage | 5.3 V |
| Output current | 1 A |
| Power consumption (typical) | 3.73 W |
| Weight & dimensions | |
| Weight | 3.86 lbs (1.75 kg) |
| Dimensions (WxDxH) | 17.2 x 6.25 x 1.75" (438.1 x 158.8 x 44.5 mm) |
| Package depth | 4.5" (114.3 mm) |
| Package width | 21.2" (539.8 mm) |
| Package height | 9.25" (234.9 mm) |
| Package weight | 5.71 lbs (2.59 kg) |
| Packaging data | |
| Package depth | 4.5" (114.3 mm) |
| Package width | 21.2" (539.8 mm) |
| Package height | 9.25" (234.9 mm) |
| Package weight | 5.71 lbs (2.59 kg) |
| Packaging content | |
| Manual | Yes |
| Cables included | HDMI |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Video | |
| Supported graphics resolutions | 4096 x 2160 |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| Maximum refresh rate | 60 Hz |
| Certificates | |
| Certification | CEC |
| Technical details | |
| Video out | HDMI |
| Plug and Play | Yes |
| HDMI version | 2.0 |
| Remote control included | Yes |
| Logistics data | |
| Products per master (outer) case | 3 pc(s) |
