Ubiquiti airMAX ac 2x2 network antenna 22 dBi
197.34 CAD
Skip to product information
3 left
Ubiquiti airMAX ac 2x2 network antenna 22 dBi
Part number
AM-5AC22-45
197.34 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
6.0 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
The airMAX®ac Sector Antennas feature significant advances in scalability, noise isolation, and beam performance to complement the Rocket™5ac radios in Point‑to‑MultiPoint (PtMP) networks. They are compatible with RocketM5 models; however, optimal performance requires the Rocket5ac.
Breakthrough Design and Performance
The airMAX®ac Sector Antennas feature carrier-class construction with an innovative deflector design and 2x2, dual-polarity performance for airMAX networks.
Superior Noise Immunity
Featuring reduced sidelobes and backlobes, the airMAX®ac Sector Antennas are engineered to reject noise interference in co‑location deployments.
Market-Leading Beam Performance
Compare the diagram of the airMAX®ac Sector Antenna, model AM-5AC22-45, to the diagram of a standard sector antenna, and note the superior noise immunity and beam performance of the AM-5AC22-45.
Industrial-Strength Construction
airMAX®ac Antennas are designed with robust mechanical design for outdoor application use.
Plug and Play Integration
Every airMAX®ac Antenna has a built-in Rocket™mount, so no tools are needed to install the Rocket BaseStation.
| Performance | |
|---|---|
| Antenna gain level (max) | 22 dBi |
| Frequency band | 5.1 - 5.8 GHz |
| Vertical beam width | 45° |
| Horizontal beam width | 45° |
| Features | |
| Antenna gain level (max) | 22 dBi |
| Frequency band | 5.1 - 5.8 GHz |
| Voltage Standing Wave Ratio (VSWR) | 1.5:1 |
| Vertical beam width | 45° |
| Polarization | Dual polarization |
| Mounting | Wall |
| Horizontal beam width | 45° |
| Product colour | White |
| Technical details | |
| Harmonized System (HS) code | 85177100 |
| Weight & dimensions | |
| Weight | 13.2 lbs (6 kg) |
| Width | 8.46" (215 mm) |
| Depth | 3.7" (94 mm) |
| Height | 29.5" (750 mm) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Harmonized System (HS) code | 85177100 |
