NETGEAR GS110TP Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Gray
Part number
GS110TP-300NAS
$260.48 CAD
GS110TP 8-Port Gigabit PoE+ Ethernet Smart Managed Pro Switch with 2 SFP Ports and Cloud Management
Description
The NETGEAR GS110TPv3 8-Port Gigabit PoE+ Ethernet Smart Managed Pro Switch comes with 8 PoE copper ports and 2 dedicated SFP ports for fiber uplinks. Cautious spender organizations can now deploy PoE devices with a reasonable PoE power budget of 55W. Each PoE port can provide up to 30 watts to power up the connected devices. Fanless, the GS110TPv3 supports perfectly silent desktop operation or wall mounting. The GS110TPv3 Smart Managed Pro Switch offers an easy-to-use, Web browser-based management GUI with configurable L2 network features like VLANs and PoE operation scheduling, allowing SMB customers to deploy PoE-based VoIP phones and IP surveillance. This switch also comes with NETGEAR Insight Cloud management activation (free for the first two devices) for anytime remote management and monitoring through an intuitive app or Cloud Portal. Advanced features such as IPv4 Layer 2+ static routing including IPv6 management, ACL, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks. The GS110TPv3 features Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings and is backed by NETGEAR’s Lifetime Limited Warranty and 24/7 support including lifetime chat.Specifications
| Management features | |
|---|---|
| Multicast support | Yes |
| Switch layer | L2/L3/L4 |
| Switch type | Managed |
| ARP inspection | Yes |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Network | |
| IGMP snooping | Yes |
| IPv4 multicast entries | 32 |
| Access Control List (ACL) IPv6 entries | 100 |
| Networking standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Full duplex | Yes |
| MAC address auto-aging supported | Yes |
| Number of VLANs | 64 |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| Virtual LAN features | |
| Number of VLANs | 64 |
| Data transmission | |
| Number of VLANs | 64 |
| Number of multicast groups filtered | 256 |
| MAC address table | 8000 entries |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Packet buffer memory | 0.5 MB |
| IPv4 & IPv6 features | |
| Access Control List (ACL) IPv6 entries | 100 |
| Performance | |
| Packet buffer memory | 0.5 MB |
| Processor frequency | 500 MHz |
| Memory type | RAM |
| Internal memory | 128 MB |
| Flash memory | 32 MB |
| Mean time between failures (MTBF) | 1200041 h |
| Security | |
| Security algorithms | 802.1x RADIUS |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) IPv6 entries | 100 |
| DHCP features | DHCP client |
| Multicast features | |
| Number of multicast groups filtered | 256 |
| Multicast support | Yes |
| IPv4 multicast entries | 32 |
| Protocols | |
| Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Design | |
| Product colour | Gray |
| LED indicators | Activity, Link, PoE, Power, Speed |
| Power | |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 15.1 W |
| Input current | 1.25 A |
| DC input voltage | 54 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) power per port | 55 W |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 69.5 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Non-operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Heat dissipation | 237.38 BTU/h |
| Weight & dimensions | |
| Width | 9.29" (236 mm) |
| Depth | 3.98" (101 mm) |
| Height | 1.06" (27 mm) |
| Weight | 21.5 oz (610 g) |
| Packaging data | |
| Package type | Box |
| Manual | Yes |
| Package width | 6.34" (161 mm) |
| Package depth | 10.5" (267 mm) |
| Package height | 3.39" (86 mm) |
| Package weight | 2.71 lbs (1.23 kg) |
| Logistics data | |
| Master (outer) case width | 10.8" (274 mm) |
| Master (outer) case length | 13.8" (350 mm) |
| Master (outer) case height | 12.2" (309 mm) |
| Master (outer) case gross weight | 17.9 lbs (8.14 kg) |
| Products per master (outer) case | 6 pc(s) |
| Packaging content | |
| Manual | Yes |
