Build and expand your network with the UniFi® Switch, part of the Ubiquiti Networks® UniFi Enterprise System. The UniFi Switch, model USW-Flex-Mini, is a smart managed Gigabit switch. It offers 5 RJ45 Ethernet ports, providing 1 Gigabit links to your devices. Power up the USW-Flex-Mini with the included USB Type-C power adapter or with 802.3af PoE Ethernet in port 1.
Ubiquiti UniFi USW Flex Mini Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White
Part number
USW-FLEX-MINI
$42.44 CAD
5x 10/100/1000, RJ-45, 2.5 W, 107.16 x 70.15 x 21.17 mm, 150 g, EU
Key Features
- Manage Your Networks from a Single Control Plane
- Intuitive and Robust Configuration, Control and Monitoring
- Remote Firmware Upgrade
- Users and Guests
- Guest Portal/Hotspot Support
Description
5-Port managed Gigabit Ethernet switch powered by 802.3af/at PoE or 5V, 1A USB-C power adapterBuild and expand your network with the UniFi® Switch, part of the Ubiquiti Networks® UniFi Enterprise System. The UniFi Switch, model USW-Flex-Mini, is a smart managed Gigabit switch. It offers 5 RJ45 Ethernet ports, providing 1 Gigabit links to your devices. Power up the USW-Flex-Mini with the included USB Type-C power adapter or with 802.3af PoE Ethernet in port 1.
Specifications
| Management features | |
|---|---|
| Switch type | Managed |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Data transmission | |
| Switching capacity | 10 Gbit/s |
| Forwarding rate | 7.44 Mpps |
| Design | |
| Rack mounting | No |
| Stackable | No |
| Product colour | White |
| LED indicators | Activity, Link, Speed, Status |
| Certification | CE, FCC, IC |
| Power | |
| Power supply included | Yes |
| Power consumption (max) | 2.5 W |
| Power connector | DC-in jack |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 4.22" (107.2 mm) |
| Depth | 2.76" (70.2 mm) |
| Height | 0.833" (21.2 mm) |
| Weight | 5.29 oz (150 g) |
| Packaging content | |
| Cables included | USB Type-C |
| Performance | |
| Stackable | No |
| Harmonized System (HS) code | 85176990 |
| Certificates | |
| Certification | CE, FCC, IC |
| Packaging data | |
| Cables included | USB Type-C |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
