Tripp Lite PDU40TDUAL power distribution unit (PDU) 40 AC outlet(s) 0U Black
457.75 CAD
Skip to product information
Out of stock
Tripp Lite PDU40TDUAL power distribution unit (PDU) 40 AC outlet(s) 0U Black
Part number
PDU40TDUAL
457.75 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
4.513 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution. Supplies equipment with continuous power from any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories. Dual independent power circuits offer all the benefits of two PDUs in a single housing, ideal for network equipment fitted with dual redundant input cables.
- 40A total single phase 120V Basic Power Distribution Unit / PDU with dual independent 120V 20A circuits (Agency de-rated to 16A per circuit)
- Functions as two PDUs built into a single 70 in. / 1778mm 0U vertical rackmount housing
- Color coded circuit identification with separate black and gray colored outlets, circuit breakers and line cords
- 40 NEMA 5-15/20R outlets (20 black / 20 gray)
- Two 10 ft. / 3m NEMA L5-20P / 5-20P compatible inputs (1 black / 1 gray)
- Two 20A circuit breakers (1 black / 1 gray)
- Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications
- 40A total single phase 120V Basic Power Distribution Unit / PDU with dual independent 120V 20A circuits (Agency de-rated to 16A per circuit)
- Functions as two PDUs built into a single 70 in. / 1778mm 0U vertical rackmount housing
- Color coded circuit identification with separate black and gray colored outlets, circuit breakers and line cords
- 40 NEMA 5-15/20R outlets (20 black / 20 gray)
- Two 10 ft. / 3m NEMA L5-20P / 5-20P compatible inputs (1 black / 1 gray)
- Two 20A circuit breakers (1 black / 1 gray)
- Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications
| Design | |
|---|---|
| PDU types | Basic |
| Mounting | Vertical |
| Product colour | Black |
| Certification | UL60950-1 (USA), CSA (Canada) |
| Rack capacity | 0U |
| Housing material | Metal |
| Ports & interfaces | |
| AC outlets quantity | 40 AC outlet(s) |
| AC outlet types | NEMA 5–15, NEMA 5–20R |
| Input connection type | NEMA 5-20P, NEMA L5-20P |
| Features | |
| Cable length | 120.1" (3.05 m) |
| Certification | UL60950-1 (USA), CSA (Canada) |
| Ergonomics | |
| Cable length | 120.1" (3.05 m) |
| Power | |
| Nominal input voltage | 100-127 V |
| Maximum current | 40 A |
| Nominal output voltage | 100-127 V |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Dimensions (WxDxH) | 1.5 x 2.99 x 70" (38 x 76 x 1778 mm) |
| Weight | 8.16 lbs (3.7 kg) |
| Weight (imperial) | 8 lbs |
| Width | 1.5" (38 mm) |
| Depth | 2.99" (76 mm) |
| Height | 70" (1778 mm) |
| Package width | 4.8" (121.9 mm) |
| Package depth | 72.4" (1840 mm) |
| Package height | 2.4" (61 mm) |
| Package weight | 9.3 lbs (4.22 kg) |
| Packaging data | |
| Package width | 4.8" (121.9 mm) |
| Package depth | 72.4" (1840 mm) |
| Package height | 2.4" (61 mm) |
| Package weight | 9.3 lbs (4.22 kg) |
| Operational conditions | |
| Storage temperature (T-T) | -15 - 50 °C |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Technical details | |
| Master (outer) case GTIN (EAN/UPC) | 10037332128406 |
| Compliance certificates | RoHS |
| Logistics data | |
| Master (outer) case width | 10.4" (264.9 mm) |
| Master (outer) case length | 73.2" (1860 mm) |
| Master (outer) case height | 8.46" (214.9 mm) |
| Master (outer) case gross weight | 58.6 lbs (26.6 kg) |
| Products per master (outer) case | 6 pc(s) |
| Country of origin | China |
