1.5kVA/900W/230V Battery Backup for PC Networks, Security Systems or Digital Signage
The SmartPro® line-interactive SMX1500LCD UPS system with AVR protection provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise that can damage valuable electronics or destroy data. The eight-outlet 230V battery backup is ideal protection for home/office workstations, VoIP systems, small business networks and other professional applications, including retail, casino and hotel/motel management.

Allows Time to Back Up Critical Files During a Blackout
Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but the line-interactive UPS system should keep an energy-efficient desktop computer with small LCD monitor powered as long as 60 minutes. During normal operation, incoming utility power keeps the replaceable internal battery fully charged, so backup power will always be available.

8 C13 Outlets Protect Your Connected Components
Eight IEC 320 C13 outlets provide battery backup, 360 joules of surge protection and voltage regulation for your computer, monitor and other crucial components.

Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts and overvoltages. The SMX1500LCD can correct brownouts as low as 144V and overvoltages as high as 282V back to nominal 230V power continuously, all while keeping the battery fully charged and ready to take over in case of power failure.

Combats Line Noise That Can Harm Equipment
EMI (electromagnetic interference) and RFI (radio frequency interference) are common causes of performance problems and can lead to incremental hardware damage, data corruption and audio/video transmission problems. The SMX1500LCD filters out this disruptive line noise on the AC line, so that it won’t affect your equipment.

Designed for High Efficiency to Help You Save Money and Protect the Environment
A 96% efficiency rating reduces BTU emissions, energy consumption and, ultimately, your energy costs.

Alarm and Easy-to-Read LCD Keep You Informed 24/7
The LCD screen indicates input voltage, battery charge level, overload, AVR, on-battery and replace battery status. It rotates for easy viewing in either rack or tower configuration. The audible alarm sounds for power failure, low battery and overloads. You may silence it using the built-in switch or disable it remotely through your PC.

Advanced Communications Ports Allow for Automatic Saves and Shutdowns
RS-232 and HID-compliant USB ports connect to a computer running free downloadable PowerAlert® software to enable safe unattended file saves and system shutdown in case of a prolonged power failure. A USB cable is included.

Versatile Installation Options
Hardware is included for mounting the SmartPro UPS system in 2U of space in an EIA-standard 19-inch 4-post or 2-post rack. It will also stand in a tower position using the included hardware for extra stability. You can rotate the LCD screen to match the UPS’ orientation. The unit has a C14 power input that connects to an AC power source with an appropriate cord.

Power
Output power capacity	1.5 kVA
Output power	900 W
Input operation voltage (min)	230 V
Input operation voltage (max)	230 V
Output operation voltage (min)	220 V
Output operation voltage (max)	240 V
Surge energy rating	890 J
Maximum current	5.5 A
Input frequency	50/60 Hz
Performance
UPS topology	Line-Interactive
Response time	4 ms
Surge protection	Yes
Waveform	Sine
LED indicators	Yes
Audible alarm(s)	Yes
Features
UPS topology	Line-Interactive
Output power capacity	1.5 kVA
Country of origin	China
Response time	4 ms
Output power	900 W
Input operation voltage (min)	230 V
Input operation voltage (max)	230 V
Output operation voltage (min)	220 V
Output operation voltage (max)	240 V
Surge energy rating	890 J
Maximum current	5.5 A
Surge protection	Yes
Waveform	Sine
Audible alarm(s)	Yes
Input frequency	50/60 Hz
Ports & interfaces
AC outlets quantity	8 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C14 coupler
USB 2.0 ports quantity	1
Serial ports quantity	1
Battery
Battery recharge time	4.5 h
Typical backup time at half load	12 min
Typical backup time at full load	4.5 min
Design
Form factor	Rackmount/Tower
Country of origin	China
Rack capacity	2U
Product colour	Black
Certification	CE, GOST, SASO, FCC Part 15 Category A, FCC Part 68
LED indicators	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	0 - 95%
Technical details
Compliance certificates	RoHS
Certificates
Certification	CE, GOST, SASO, FCC Part 15 Category A, FCC Part 68
Compliance certificates	RoHS
Weight & dimensions
Width	17.3" (438.2 mm)
Depth	10.5" (266.7 mm)
Height	3.5" (88.9 mm)
Weight	29.3 lbs (13.3 kg)
Package width	15.3" (388.1 mm)
Package depth	21.8" (553 mm)
Package height	7.8" (198.1 mm)
Package weight	34.6 lbs (15.7 kg)
Packaging data
Package width	15.3" (388.1 mm)
Package depth	21.8" (553 mm)
Package height	7.8" (198.1 mm)
Package weight	34.6 lbs (15.7 kg)
Logistics data
Country of origin	China
Products per master (outer) case	1 pc(s)
Master (outer) case width	15.3" (388.1 mm)
Master (outer) case length	21.8" (553 mm)
Master (outer) case height	7.8" (198.1 mm)
Master (outer) case gross weight	34.6 lbs (15.7 kg)
Master (outer) case GTIN (EAN/UPC)	10037332126075
