ATEN VC480 video signal converter
299.47 CAD
Skip to product information
Out of stock
ATEN VC480 video signal converter
Part number
VC480
299.47 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
0.29 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
- Converts an 3G/HD/SD-SDI input signal to HDMI formats in real time while avoiding transformation loss for both audio and video signals
- Supports additional analog stereo audio and coaxial digital audio
- HDMI (Deep Color)
- LED indication of power and signal status
- Supports an SDI distance of up to 90M (3G-SDI), 150M (HDSDI) or 300M (SD-SDI) of RG6
- Supported SDI formats:
- • SD-SDI (SMPTE 259M, up to 270Mbps)
- • HD-SDI (SMPTE 292M, 296M, up to 1.485Gbps)
- • 3G-SDI (SMPTE 424M, 425M level A,B, up to 2.97Gbps)
- Video Support:
- 525i@59.96, 625i@50
- 720p@23.98/24/25/29.94/30/50/59.94/60
- 1080i@50/59.94/60
- 1080p@23.97/24/25/29.97/30/50/59.94/60
- Buffered loop-through output provides extended monitoring
- Supports 8 audio channels @48kHz rate
- Features automatic detection of 3G/HD/SD-SDI signals
- Reclocking SDI signals for cascading and thus longer transmission
- Locking power connector for secure communications
The VC480 3G/HD/SD SDI to HDMI Converter provides a professional way to exchange high definition signals in real time. The SDI and HDMI signal conversion is 100% digital and guarantees no loss of quality for both the audio and video transmission. The VC480 is the most dependable way to convert signals with confidence when monitoring in any post or broadcast application.
| Other features | |
|---|---|
| Product colour | Black |
| Features | |
| Product colour | Black |
| Ports & interfaces | |
| Output interface | HDMI, BNC |
| Host interface | BNC |
| Power | |
| Input voltage | 5 V |
| Technical details | |
| Harmonized System (HS) code | 85176990 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Weight & dimensions | |
| Width | 4.28" (108.7 mm) |
| Depth | 4.84" (123 mm) |
| Height | 1.2" (30.5 mm) |
| Weight | 10.2 oz (290 g) |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
