Ubiquiti AirFiber AF-5XHD 1000 Mbit/s White Power over Ethernet (PoE)
535.30 CAD
Skip to product information
In stock
Ubiquiti AirFiber AF-5XHD 1000 Mbit/s White Power over Ethernet (PoE)
Part number
AF-5XHD
535.30 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
0.35 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
- 1 Gbps+ Throughput
- 4096 QAM Modulation
- 2 Million+ Packets per Second
- Proprietary RF Filtering
The New Standard for WISP Backhaul Performance
True 1Gbps+ Spectrally Efficient, Noise Resilient PTP Technology Specifically Designed for WISP’s
Complete Custom Hardware for the WISP, right down to the Silicon
Our core communications processing engine surpasses all of the limitations inherent to generic Wi‐Fi chips.
Game-Changing LTU Technology
Spectral Efficiency Comparison of 802.11n, 802.11ac, airFiber Original, and LTU by year.
IP-67 Durability
airFiber 5XHD is Water Resistant and Perfect for any Weather Conditions.
True 1Gbps+ Spectrally Efficient, Noise Resilient PTP Technology Specifically Designed for WISP’s
Complete Custom Hardware for the WISP, right down to the Silicon
Our core communications processing engine surpasses all of the limitations inherent to generic Wi‐Fi chips.
Game-Changing LTU Technology
Spectral Efficiency Comparison of 802.11n, 802.11ac, airFiber Original, and LTU by year.
IP-67 Durability
airFiber 5XHD is Water Resistant and Perfect for any Weather Conditions.
| Performance | |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| 5 GHz | Yes |
| Frequency band | 5.150 - 5.250 / 5.740 - 5.850 GHz |
| GPS (satellite) | Yes |
| Transmitting power | 29 dBmW |
| Modulation | QAM |
| Maximum outdoor range | 7874015.7" (200000 m) |
| Channel bandwidth | 100 MHz |
| Certification | FCC |
| Operating system installed | AirOS |
| Features | |
| Maximum data transfer rate | 1000 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| 5 GHz | Yes |
| Frequency band | 5.150 - 5.250 / 5.740 - 5.850 GHz |
| GPS (satellite) | Yes |
| Transmitting power | 29 dBmW |
| Modulation | QAM |
| Maximum outdoor range | 7874015.7" (200000 m) |
| Channel bandwidth | 100 MHz |
| Operating system installed | AirOS |
| Security | |
| Security algorithms | 256-bit AES |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| Power | |
| Power consumption (max) | 12 W |
| Output voltage | 24 V |
| Output current | 1 A |
| Power over Ethernet (PoE) | Yes |
| AC input voltage | 20 - 50 V |
| Design | |
| Internal | No |
| Placement | Wall |
| International Protection (IP) code | IP67 |
| Product colour | White |
| Certification | FCC |
| Antenna | |
| Antenna connector type | RP-SMA |
| Technical details | |
| Harmonized System (HS) code | 85176990 |
| Certificates | |
| Certification | FCC |
| Weight & dimensions | |
| Width | 3.23" (82 mm) |
| Depth | 1.89" (48 mm) |
| Height | 8.82" (224 mm) |
| Weight | 12.3 oz (350 g) |
| Packaging data | |
| Mounting kit | Yes |
| Packaging content | |
| Mounting kit | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 55 °C |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
