LSZH Jacket | Aramid Fiber Sheath | Ideal for SANs, data servers, SFP+

The LC to LC Multimode Duplex Fiber Optic Patch cable facilitates reliable connectivity across 40 and 100 Gigabit networks.

Engineered for Optimal Performance

With laser-optimized multimode fiber (LOMMF), the OM4 fiber patch cable is ideal for 850 nm and 1350 nm Vertical Cavity Surface Emitting Laser (VCSEL) and LED sources. Precision-manufactured ceramic ferrules ensure correct fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics over older PC polishing techniques which may negatively affect performance.

Wide Compatibility

This multimode 50/125µm fiber optic patch cord is backward compatible with OM3 and 1/10/40 Gbps networks, ensuring a reliable connection with legacy fiber environments.

Flame Resistant

Housed in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to high heat or in the event of a fire. It enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where building codes are a consideration.

Each OM4 fiber cable is also individually tested and certified to be within acceptable optical insertion loss limits for guaranteed compatibility and 100% reliability.

The StarTech.com Advantage

Features
Cable length	590.6" (15 m)
Fibre optic type	OM4
Connector 1	LC
Connector 2	LC
Full duplex	Yes
Core diameter	50 µm
Cladding diameter	125 µm
Jacket material	Low smoke zero halogen (LSZH)
Fiber mode structure	Multi-mode
Data transfer rate	100 Gbit/s
Operating temperature (T-T)	-20 - 60 °C
Storage temperature (T-T)	-20 - 60 °C
Wavelengths supported	850 nm
Harmonized System (HS) code	85447000
Product colour	Aqua color
Connector 2 gender	Male
Connector 1 gender	Male
Technical details
Sustainability compliance	Yes
Doesn't contain	Halogen
Compliance certificates	CE, RoHS
Operational conditions
Operating temperature (T-T)	-20 - 60 °C
Storage temperature (T-T)	-20 - 60 °C
Weight & dimensions
Cable length	590.6" (15 m)
Weight	6.35 oz (180 g)
Package width	8.66" (220 mm)
Package depth	7.87" (200 mm)
Package height	1.26" (32 mm)
Package weight	7.23 oz (205 g)
Packaging data
Package width	8.66" (220 mm)
Package depth	7.87" (200 mm)
Package height	1.26" (32 mm)
Package weight	7.23 oz (205 g)
Quantity per pack	1 pc(s)
Logistics data
Harmonized System (HS) code	85447000
Quantity per pack	1 pc(s)
