Fiber to Copper Media Converter | 10GBASE/1000BASE | 10Gbps/1Gbps Unmanaged | Single Mode & Multimode

This Ethernet fiber media converter offers an easy, cost-effective way to extend your network over fiber, using the SFP+ of your choice. It converts a copper RJ45 Ethernet connection to 10Gbps or 1Gbps fiber, to extend your network over longer distances or connect workstations to switches.

Cost-Effective Extensions and Flexible Performance

The RJ45 to fiber media converter provides a cost-efficient way to connect an Ethernet network to remote devices over a fiber backbone. It features an open SFP+ slot that supports the MSA-compliant 10 Gigabit SFP+ or 1 Gigabit SFP that best suits your fiber connection setup (single mode/multimode) and distance requirements.

A Versatile Way to Connect Different Networks

The 10Gb/1Gb fiber media converter supports auto-negotiation while providing versatile connectivity to existing networks and devices, maximizing the usage and performance of legacy equipment.

Network Compatibility:

• 10GBASE-ER
• 10GBASE-LR
• 10GBASE-LW
• 10GBASE-EW
• 10GBASE-R
• 10GBASE-SR
• 10GBASE-SW
• 10GBASE-T
• 1000BASE-T
• 1000BASE-SX
• 1000BASE-LX

Fast and Easy Installation

The unmanaged fiber media converter has a standalone compact design with simple plug-and-play setup to ensure fast and easy installation.

StarTech.com Fiber Media Converters

Overcome the distance limitations of traditional network cables with StarTech.com fiber media converters. Our converters connect different types of network cabling and help you extend networks between buildings and over longer distances. Whether you need to extend a network connection 550 m or 40 km, we can help you.

The StarTech.com Advantage

Network
Fiber optic connector	SFP+
Maximum data transfer rate	10000 Mbit/s
Auto-negotiation	Yes
Jumbo frames	9000
Fiber ethernet cabling technology	10GBASE-LR, 10GBASE-SR
Networking standards	IEEE 802.1Q, IEEE 802.3ae, IEEE 802.3an
Jumbo frames support	Yes
Ethernet LAN data rates	10,100,1000,1200,2500,5000,10000 Mbit/s
Ethernet interface type	10 Gigabit Ethernet
Auto MDI/MDI-X	Yes
Performance
Auto-negotiation	Yes
Jumbo frames support	Yes
Fiber mode structure	Multi-mode, Single-mode
Ports & interfaces
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Fiber ports quantity	1
Fiber optic connector	SFP+
Design
Internal	No
LED indicators	Link, Power
Housing material	Aluminum
Product colour	Black
Certification	CE, FCC, UL, PSE
Power
Input current	250 A
Output voltage	5 V
Output current	2 A
Power plug type	Type M
External power adapter	Yes
Power over Ethernet (PoE)	No
Weight & dimensions
Width	3.15" (80 mm)
Depth	4.8" (122 mm)
Height	1.18" (30 mm)
Weight	9.67 oz (274 g)
Package width	5.67" (144 mm)
Package depth	8.15" (207 mm)
Package height	1.5" (38 mm)
Package weight	12.3 oz (350 g)
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 120 °C
Operating relative humidity (H-H)	10 - 90%
Packaging data
Package width	5.67" (144 mm)
Package depth	8.15" (207 mm)
Package height	1.5" (38 mm)
Package weight	12.3 oz (350 g)
Packaging content
AC adapter included	Yes
Manual	Yes
Technical details
Harmonized System (HS) code	85176990
Compliance certificates	RoHS
Certificates
Certification	CE, FCC, UL, PSE
Logistics data
Master (outer) case width	12.6" (320 mm)
Master (outer) case length	21.7" (550 mm)
Master (outer) case height	12.6" (320 mm)
Products per master (outer) case	20 pc(s)
Harmonized System (HS) code	85176990
