ATEN VS0801HB video switch HDMI
312.54 CAD
Skip to product information
Out of stock
ATEN VS0801HB video switch HDMI
Part number
VS0801HB
312.54 CAD
Taxes and shipping calculated at checkout.
Enjoy Free Shipping on orders over 2000 CAD
Shipping time varies based your on location.
Specifications
Weight
2.14 kg
Shipping + Returns
Shipping Policy
Ships to: Canada & USA via UPS, DHL, & Canada Post.
Fast Dispatch: Orders before 2 PM EST process same-day.
Options: Standard (Ground) and Express (Air) shipping available.
Heavy Items: Heavy freight usually requires1-2 extra days for Processing
Returns & Refunds
Return Period: Request a return within 14 days of delivery.
Restocking Fee: 20% fee applies to non-defective/change-of-mind returns.
Condition: Items must be returned in original packaging (New or Like New).
Final Sale: Software, licenses, and special orders cannot be returned.
- Allows up to 8 HDMI sources to be connected to one HDMI display
- HDMI (3D, Deep Color, 4K); HDCP 2.2 compliant
- Superior video quality - True 4K resolutions of 4K x 2K @ 60 Hz (4:4:4) and standard 1080p (1920 x 1080 @ 60 Hz)
- Supports HDR10+
- Built-in bi-directional RS-232 serial port for high-end system control
- Auto switching modes for auto port selection
- Supports IR extension
- Clear LED indication of device status
- Plug-and-play
- Rack Mountable
The ATEN VS0801HB is designed for applications that require the routing of 8 sources to one compatible display device. It supports video resolutions up to True 4K (4096 x 2160 @ 60Hz 4:4:4), data rates up to 18 Gbps, 3D, Deep Color up to 12-bit, and HD lossless audio formats. The VS0801HB features Auto Switching modes for auto port selection. Multiple convenient control options include front panel pushbuttons, bi-directional RS-232, IR, and auto switch, allowing for easy integration.
Engineered to meet today’s demand of True 4K signal transmission and user-oriented design, the ATEN VS0801HB is a powerful solution for a wide range of settings, such as home theater, meeting rooms, trade shows, and shopping centers.
Engineered to meet today’s demand of True 4K signal transmission and user-oriented design, the ATEN VS0801HB is a powerful solution for a wide range of settings, such as home theater, meeting rooms, trade shows, and shopping centers.
| Ports & interfaces | |
|---|---|
| Video port type | HDMI |
| Video out | 1 x HDMI Type A Female (Black) |
| Video in | 8 x HDMI Type A Female (Black) |
| RS-232 ports | 1 |
| HDMI version | 2.0 |
| HDMI ports quantity | 8 |
| Number of HDMI outputs | 1 |
| HDMI in | 8 |
| DC-in jack | Yes |
| Features | |
| Product colour | Black |
| Output impedance | 100 Ω |
| Input impedance | 100 Ω |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160 |
| Maximum resolution | 4096 x 2160 pixels |
| Maximum refresh rate | 60 Hz |
| Maximum operating distance | 118.1" (3 m) |
| Material | Metal |
| HDCP | Yes |
| HD type | 4K Ultra HD |
| Bandwidth | 6 Gbit/s |
| Bandwidth | 600 MHz |
| 3D | Yes |
| Power | |
| AC adapter input voltage | 5.3 V |
| Power consumption (typical) | 3.73 W |
| Weight & dimensions | |
| Width (imperial) | 6.23" |
| Width | 6.23" (158.3 mm) |
| Weight | 4.72 lbs (2.14 kg) |
| Height (imperial) | 1.73" |
| Height | 1.73" (44 mm) |
| Depth | 17.2" (437.2 mm) |
| Depth (imperial) | 17.21" |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 80% |
